Smart Control System BLE 120-277V Microwave Sensor
Smart Control System BLE 120-277V Microwave Sensor
Model: E2-PP02
Microwave Sensor, Daylight Harvesting, IR Switch Control, Bluetooth Low Energy
Integrated Photocell
0-10V Dimmable
120-277 Volt
Specifications
| Voltage | 120-277V |
| Dimming | 0-10V |
| Frequency | 50–60 Hz |
| Operating Temperature | -40°C(-40°F)-70°C(158°F) |
| Features | Non-Waterproof; Cable with Quick Connector |
| Connection Type | Wire leads (wire colour designation) |
| Current | up to 25mA (sinking current, maximum) |
| Compatibility | existing 1–10V LED luminaires (existing 1–10V LED luminaires) |
| Color | White |
| Connectivity | Bluetooth Low Energy |
| Control Type | IR Switch |
| Daylight Harvesting | Yes |
| Encryption | AES 128-bit (AES) |
| Mesh Range | 100 ft (node-to-node) / 50 ft (node-to-device commissioning) |
| Photocell | Included |
| Photosensitive Range | 10–1,000 lux |
| Sensor Type | Microwave |
| Switching Capacity | up to 60W (maximum, LED driver only) |
| Switching Current Capacity | up to 5A (maximum, LED driver only) |
| Control Functions | individual addressability / grouping / time-clock scheduling for individual lights, groups or scenes / manual ON/OFF / automatic ON/OFF / automatic partial ON/OFF / adjustable microwave sensitivity / constant illumination |
| Standards | UL 1376 / DLC networked lighting control technical requirements / CE / RoHS |
| Warranty | 5 years |
| Listings | DLC Premium / cULus |
| Family | Occupancy and daylight sensor |
Description
A Bluetooth Low Energy microwave and daylight sensor system that retrofits indoor fixtures, pairing a 120–277V power pack with a fixture-mounted sensor. It is built for existing 1–10V LED luminaires, including panels, downlights, pendant lights, low bays, high bays and track lighting, adding occupancy sensing, daylight harvesting and constant illumination.
Control includes individual addressability, grouping and time-clock scheduling for individual lights, groups or scenes, with manual on/off, automatic on/off and automatic partial on/off. It provides 0–10V dimming, adjustable microwave sensitivity, and a built-in light sensor reading 10–1,000 lux. The white sensor mounts magnetically, the power pack connects by wire leads, and it controls loads of up to 60W and 5A, with AES-encrypted connections.
cULus and DLC Premium listed, CE and RoHS compliant, conforming to UL 1376 and DLC networked lighting control technical requirements, with a 5-year warranty.
Specifications
| General | |
|---|---|
| Family | Occupancy and daylight sensor |
| Features | Non-Waterproof; Cable with Quick Connector |
| Electrical | |
|---|---|
| Connection Type | Wire leads (wire colour designation) |
| Current | up to 25mA (sinking current, maximum) |
| Frequency | 50–60 Hz |
| Voltage | 120–277V |
| Compatibility | existing 1–10V LED luminaires (existing 1–10V LED luminaires) |
| Physical | |
|---|---|
| Ambient Temperature | -40–70 °C (operating) |
| Finish | White |
| Controls | |
|---|---|
| Connectivity | Bluetooth Low Energy |
| Control Type | IR Switch |
| Daylight Harvesting | Yes |
| Dimming Type | 0–10V |
| Encryption | AES 128-bit (AES) |
| Mesh Range | 100 ft (node-to-node) / 50 ft (node-to-device commissioning) |
| Photocell | Included |
| Photosensitive Range | 10–1,000 lux |
| Sensor Type | Microwave |
| Switching Capacity | up to 60W (maximum, LED driver only) |
| Switching Current Capacity | up to 5A (maximum, LED driver only) |
| Control Functions | individual addressability / grouping / time-clock scheduling for individual lights, groups or scenes / manual ON/OFF / automatic ON/OFF / automatic partial ON/OFF / adjustable microwave sensitivity / constant illumination |
| Warranty | |
|---|---|
| Warranty | 5 years |
| Certifications | cULus / DLC Premium |
| Standards | UL 1376 / DLC networked lighting control technical requirements / CE / RoHS |
