Down light Panel Disk Light with Surface Mount
Down light Panel Disk Light with Surface Mount
12W, Up to 900 Lumens
2700K/3000K/3500K/4000K/5000K CCT Selectable
TRIAC Dimmable
120-277 Volt
Damp Location
Specifications
| Size | 7 in |
| Beam Angle | 120° |
| CCT | 2700 / 3000 / 3500 / 4000 / 5000K |
| CRI | 90 |
| Color Consistency (SDCM) | up to 5 SDCM |
| Efficacy | 75 lm/W (±5%) |
| Lumens | 900 lm (±5%) |
| Optical Arrangement | Edge-lit |
| Frequency | 50 / 60 Hz |
| Power Factor | 0.9+ |
| Voltage | 120–277V |
| Wattage | 12W |
| Compatibility | DVCL-153P-WH (Lutron dimmers, DVCL-153P-WH) / DVELV-300P-WH (Lutron dimmers, DVELV-300P-WH) / S-600P-WH (Lutron dimmers, S-600P-WH) / MACL-153M-WH (Lutron dimmers, MACL-153M-WH) / DVSCCL-153P-ES (Lutron dimmers, DVSCCL-153P-ES) / PD-6WCL (Caseta Wireless dimmer) (Lutron dimmers, PD-6WCL) / SELV-300P-IV (Lutron dimmers, SELV-300P-IV) / DVWCL-153PH-WH (Lutron dimmers, DVWCL-153PH-WH) / DVCL-253P-WH (Lutron dimmers, DVCL-253P-WH) / CTCL-153P-IV (Lutron dimmers, CTCL-153P-IV) / AYCL-253P-WH (Lutron dimmers, AYCL-253P-WH) / 6674 (Leviton dimmers, 6674) / 6615-POW (Leviton dimmers, 6615-POW) / 6633 (Leviton dimmers, 6633) / RHCL453PW (Leviton dimmers, RHCL453PW) / TSLO6-1LW (Leviton dimmers, TSLO6-1LW) |
| Ambient Temperature | -10–45 °C (operating) |
| Diameter | 180 mm |
| Height | 18 mm |
| Mounting | Surface (twist-and-lock brackets) |
| CCT Selectable | Yes, switchable |
| Dimming | TRIAC |
| Flame Retardant | V0 |
| Location Rating | Damp location |
| Protection | Surge protection (surge) |
| Standards | California Title 24 / FCC |
| Lifespan | 50,000+ hours |
| Warranty | 5 years |
| Listings | ETL |
| Family | Downlight |
Description
This flush LED surface-mount panel offers five color temperature options in one unit, 2700K, 3000K, 3500K, 4000K or 5000K, so you can set the atmosphere to suit the space. Its TRIAC dimming works with the recommended dimmer list for flexible control.
It is a low-profile, edge-lit 7-inch round panel, 180 mm across and 18 mm tall, that mounts to the surface with twist-and-lock brackets. It delivers 900 lumens at 12W and 75 lm/W, with CRI 90, color consistency within 5 SDCM and a 120° beam, and runs on 120–277V with surge protection. The V0 flame-retardant housing is rated for damp locations and operates from -10 to 45 °C.
ETL listed and California Title 24 compliant, with a 50,000+ hour rated life and a 5-year warranty.
Specifications
| General | |
|---|---|
| Family | Downlight |
| Size | 7 in |
| Light | |
|---|---|
| Beam Angle | 120° |
| CCT | 2700 / 3000 / 3500 / 4000 / 5000K |
| CRI | 90 |
| Color Consistency (SDCM) | up to 5 SDCM |
| Efficacy | 75 lm/W (±5%) |
| Lumens | 900 lm (±5%) |
| Optical Arrangement | Edge-lit |
| Electrical | |
|---|---|
| Frequency | 50 / 60 Hz |
| Power Factor | 0.9+ |
| Voltage | 120–277V |
| Wattage | 12W |
| Compatibility | DVCL-153P-WH (Lutron dimmers, DVCL-153P-WH) / DVELV-300P-WH (Lutron dimmers, DVELV-300P-WH) / S-600P-WH (Lutron dimmers, S-600P-WH) / MACL-153M-WH (Lutron dimmers, MACL-153M-WH) / DVSCCL-153P-ES (Lutron dimmers, DVSCCL-153P-ES) / PD-6WCL (Caseta Wireless dimmer) (Lutron dimmers, PD-6WCL) / SELV-300P-IV (Lutron dimmers, SELV-300P-IV) / DVWCL-153PH-WH (Lutron dimmers, DVWCL-153PH-WH) / DVCL-253P-WH (Lutron dimmers, DVCL-253P-WH) / CTCL-153P-IV (Lutron dimmers, CTCL-153P-IV) / AYCL-253P-WH (Lutron dimmers, AYCL-253P-WH) / 6674 (Leviton dimmers, 6674) / 6615-POW (Leviton dimmers, 6615-POW) / 6633 (Leviton dimmers, 6633) / RHCL453PW (Leviton dimmers, RHCL453PW) / TSLO6-1LW (Leviton dimmers, TSLO6-1LW) |
| Physical | |
|---|---|
| Ambient Temperature | -10–45 °C (operating) |
| Diameter | 180 mm |
| Height | 18 mm |
| Mounting | Surface (twist-and-lock brackets) |
| Controls | |
|---|---|
| CCT Selectable | Yes, switchable |
| Dimming Type | TRIAC |
| Warranty | |
|---|---|
| Rated Life | 50,000+ hours |
| Warranty | 5 years |
| Certifications | ETL |
| Flame Retardant | V0 |
| Location Rating | Damp location |
| Protection | Surge protection (surge) |
| Standards | California Title 24 / FCC |
