Slim Down Lights with Emergency Battery 4 Inch Fire Rated (TRIAC Dimming)
Slim Down Lights with Emergency Battery 4 Inch Fire Rated (TRIAC Dimming)
Model: E2-DL-SLIM-4Inch-9W-27/30/35/40/50K-E-F
9W
2700K/3000K/3500K/4000K/5000K CCT Selectable
Built-in 4W Emergency Battery, 90+ Minutes
TRIAC Dimmable
100-277 Volt
Specifications
| Wattage | 9W |
| Voltage | 100–277V |
| Dimming | TRIAC |
| CCT | 2700 / 3000 / 3500 / 4000 / 5000K |
| CRI | > 90 |
| Lifespan | 50,000 hours |
| Dimensions | 125 × 24 mm (4.75" × 1") |
| Listings | cETLus |
| Warranty | 5-Year Manufacturer's Warranty |
| Size | 4 in |
| Cutout | 105 mm |
| Diameter | 125 mm |
| Height | 24 mm |
| Material | Fireproof cotton |
| Mounting | Spring clips |
| Emergency Backup | Integrated |
| Emergency Lumens | 400 lm (at 4W) |
| Emergency Power | 4W (emergency battery pack) |
| Emergency Runtime | 90+ minutes |
| CCT Selectable | Yes, switchable |
| Dimmable | Yes |
| Air-Tight | Yes |
| Fire Rating | 2 hours |
| IC Rating | Yes |
| Standards | FCC / RoHS |
| Family | Downlight |
| Series | Ultra Slim Downlight (SLIM, SLIM-E) |
Description
This 4-inch fire-rated ultra-thin downlight has a pre-wired emergency battery that keeps it lit for 90+ minutes during a power outage. It carries a 2-hour fire rating and is Type IC and air-tight rated, so it installs without additional housing.
It draws 9W, with color temperature selectable at 2700K, 3000K, 3500K, 4000K or 5000K and CRI 90+. It is TRIAC dimmable and runs on 100–277V. Fireproof cotton forms part of its construction, spring clips secure it in a 105 mm cutout, and plenum-rated cable connects it to its driver connection box. The fixture is 125 mm across and 24 mm tall, for residential and commercial ceilings.
cETLus listed, with a 50,000-hour rated life and a 5-year warranty.
Specifications
| General | |
|---|---|
| Family | Downlight |
| Series | Ultra Slim Downlight (SLIM, SLIM-E) |
| Size | 4 in |
| Light | |
|---|---|
| CCT | 2700 / 3000 / 3500 / 4000 / 5000K |
| CRI | 90+ |
| Electrical | |
|---|---|
| Voltage | 100–277V |
| Wattage | 9W |
| Physical | |
|---|---|
| Cutout | 105 mm |
| Diameter | 125 mm |
| Dimensions | 125 × 24 mm |
| Height | 24 mm |
| Material | Fireproof cotton |
| Mounting | Spring clips |
| Emergency | |
|---|---|
| Emergency Backup | Integrated |
| Emergency Lumens | 400 lm (at 4W) |
| Emergency Power | 4W (emergency battery pack) |
| Emergency Runtime | 90+ minutes |
| Controls | |
|---|---|
| CCT Selectable | Yes, switchable |
| Dimmable | Yes |
| Dimming Type | TRIAC |
| Warranty | |
|---|---|
| Rated Life | 50,000 hours |
| Warranty | 5 years |
| Air-Tight | Yes |
| Certifications | cETLus |
| Fire Rating | 2 hours |
| IC Rating | Yes |
| Standards | FCC / RoHS |
