LED Flat Panel 1X4 CCT & Wattage Tunable
LED Flat Panel 1X4 CCT & Wattage Tunable
Model: E2-BPL-DPS-1X4-18/24/28W-35/40/50K
18/24/28W Wattage Selectable, Up to 3,570 Lumens
3500K/4000K/5000K CCT Selectable
0-10V Dimmable
120-277 Volt
Damp Location
Specifications
| Wattage | 18W / 24W / 28W |
| Voltage | 120-277V |
| Dimming | 0-10V |
| CCT | 3500K / 4000K / 5000K |
| CRI | > 80 |
| Lumens | 2295 lm / 3060 lm / 3570 lm |
| Lifespan | 50,000 hours |
| Listings | DLC Premium / UL (damp location) |
| Warranty | 5-Year Manufacturer's Warranty |
| Size | 1×4 ft |
| Beam Angle | 120° |
| Color Consistency (SDCM) | up to 5 SDCM |
| Efficacy | 127.5 lm/W |
| UGR | up to 22 |
| Ambient Temperature | -20–35 °C (operating) |
| Dimensions | 47.8 × 11.9 × 1.6 in |
| Color | White |
| Material | Aluminum (frame) / Steel (back enclosure) |
| Mounting | Grid lay-in (integral earthquake clips) |
| Suspension Adjustment Range | Yes (suspension kit, 0.6–3.9 ft) |
| Weight | 5.2 lb |
| CCT Selectable | Yes, switchable |
| Dimming Range | 10–100% |
| Wattage Selectable | Yes |
| IC Rating | Yes |
| Location Rating | Damp location |
| Standards | FCC / RoHS |
| Pack Quantity | 2 (carton) / 32 (pallet) |
| Family | Troffer and flat panel |
| Series | Back-lit flat panel (BPL) |
Description
A 1×4 backlit LED flat panel with separate wattage and color temperature switches, so one fixture can be set for the space it goes into. Wattage is selectable at 18, 24 or 28W, giving 2,295, 3,060 or 3,570 lumens at 127.5 lm/W, and color temperature at 3500K, 4000K or 5000K with CRI 80 and color consistency within 5 SDCM.
It dims from 10–100% on 0–10V controls and runs on 120–277V, with UGR up to 22. A white aluminum frame and steel back enclosure measure 47.8 × 11.9 × 1.6 in, and integral earthquake clips hold it in a recessed T-bar grid ceiling.
UL listed for damp locations, IC rated and DLC Premium listed, with a 50,000-hour rated life and a 5-year warranty.
Specifications
| General | |
|---|---|
| Family | Troffer and flat panel |
| Series | Back-lit flat panel (BPL) |
| Size | 1×4 ft |
| Light | |
|---|---|
| Beam Angle | 120° |
| CCT | 3500 / 4000 / 5000K |
| CRI | 80 |
| Color Consistency (SDCM) | up to 5 SDCM |
| Efficacy | 127.5 lm/W |
| Lumens | 2,295 / 3,060 / 3,570 lm |
| UGR | up to 22 |
| Electrical | |
|---|---|
| Voltage | 120–277V |
| Wattage | 18 / 24 / 28W |
| Physical | |
|---|---|
| Ambient Temperature | -20–35 °C (operating) |
| Dimensions | 47.8 × 11.9 × 1.6 in |
| Finish | White |
| Material | Aluminum (frame) / Steel (back enclosure) |
| Mounting | Grid lay-in (integral earthquake clips) |
| Suspension Adjustment Range | Yes (suspension kit, 0.6–3.9 ft) |
| Weight | 5.2 lb |
| Controls | |
|---|---|
| CCT Selectable | Yes, switchable |
| Dimming Range | 10–100% |
| Dimming Type | 0–10V |
| Wattage Selectable | Yes |
| Warranty | |
|---|---|
| Rated Life | 50,000 hours |
| Warranty | 5 years |
| Certifications | UL (damp location) / DLC Premium |
| IC Rating | Yes |
| Location Rating | Damp location |
| Standards | FCC / RoHS |
| Pack Quantity | 2 (carton) / 32 (pallet) |
