LED Flat Panel 2X2 CCT & Wattage Tunable
LED Flat Panel 2X2 CCT & Wattage Tunable
Model: E2-BPL-2X2-20/25/30/35/40W-30/35/40/50/65K
20/25/30/35/40W Wattage Selectable, Up to 5,000 Lumens
3000K/3500K/4000K/5000K/6500K CCT Selectable
0-10V Dimmable
120-277 Volt
Specifications
| Wattage | 20W / 25W / 30W / 35W / 40W |
| Voltage | 120-277V |
| Dimming | 0-10V |
| CCT | 3000K / 3500K / 4000K / 5000K / 6500K |
| CRI | > 80 |
| Lumens | 2500 lm / 3125 lm / 3750 lm / 4375 lm / 5000 lm |
| Lifespan | 50,000 hours (at L70) |
| Listings | DLC Premium / ETL / UL |
| Warranty | 5-Year Manufacturer's Warranty |
| Size | 2×2 ft |
| Efficacy | 125 lm/W |
| Power Factor | 0.92 |
| Ambient Temperature | -4–122 °F (working) |
| Dimensions | 23.7 × 23.7 × 1.5 in |
| Mounting | Grid lay-in (integral earthquake clips) |
| Weight | 6 lb (net) |
| CCT Selectable | Yes, switchable |
| Wattage Selectable | Yes |
| Standards | FCC / CE / RoHS |
| Accessories | Surface-mount kit (on request) / Suspension cable kit (on request) |
| Family | Troffer and flat panel |
| Series | Back-lit flat panel (BPL) |
Description
This versatile 2×2 LED flat panel offers a wide range of settings to match your lighting needs, for ambient light in offices, schools and healthcare facilities. Choose a power level of 20, 25, 30, 35 or 40W, giving 2,500, 3,125, 3,750, 4,375 or 5,000 lumens at 125 lm/W, and a color temperature of 3000K, 3500K, 4000K, 5000K or 6500K.
Brightness can be fine-tuned with 0–10V dimming, and the panel runs on standard 120–277V circuits with CRI 80+ and a 0.92 power factor. It measures 23.7 × 23.7 × 1.5 in and recesses into T-bar grid ceilings with integral earthquake clips.
ETL, UL and DLC Premium listed, with a 50,000-hour rated life and a 5-year warranty.
Specifications
| General | |
|---|---|
| Family | Troffer and flat panel |
| Series | Back-lit flat panel (BPL) |
| Size | 2×2 ft |
| Light | |
|---|---|
| CCT | 3000 / 3500 / 4000 / 5000 / 6500K |
| CRI | 80+ |
| Efficacy | 125 lm/W |
| Lumens | 2,500 / 3,125 / 3,750 / 4,375 / 5,000 lm |
| Electrical | |
|---|---|
| Power Factor | 0.92 |
| Voltage | 120–277V |
| Wattage | 20 / 25 / 30 / 35 / 40W |
| Physical | |
|---|---|
| Ambient Temperature | -4–122 °F (working) |
| Dimensions | 23.7 × 23.7 × 1.5 in |
| Mounting | Grid lay-in (integral earthquake clips) |
| Weight | 6 lb (net) |
| Controls | |
|---|---|
| CCT Selectable | Yes, switchable |
| Dimming Type | 0–10V |
| Wattage Selectable | Yes |
| Warranty | |
|---|---|
| Rated Life | 50,000 hours (at L70) |
| Warranty | 5 years |
| Certifications | ETL / UL / DLC Premium |
| Standards | FCC / CE / RoHS |
| Accessories | Surface-mount kit (on request) / Suspension cable kit (on request) |
