E2 Cylinder Pendant
E2 Cylinder Pendant
12/18/25W Wattage Selectable
2700K/3000K/3500K/4000K CCT Selectable
0-10V Dimmable
120-277 Volt
Damp Location
Specifications
| Light Source | COB LED |
| Size | 4 / 6 / 8 in |
| Beam Angle | 15° (narrow) / 24° (medium) / 36° (wide) / 60° (flood) |
| CCT | 2700 / 3000 / 3500 / 4000K |
| CRI | 80+ (standard) |
| Power Factor | 0.9+ |
| THD | up to 20% |
| Voltage | 120–277V |
| Wattage | 4 in: 12 / 18 / 25W |
| Compatibility | Lutron Diva-Dvtv (dimmers, Diva-Dvtv) / Leviton IP-710-DL (dimmers, IP-710-DL) |
| Ambient Temperature | -20–40 °C (operating) |
| Coating | Powder coating |
| Color | White / Black / Custom color |
| Mounting | Cable suspended / Pendant stem / 4 in: Cable suspended / 6 in / 8 in: Cable suspended |
| Fits | RJ: flat canopy for recessed J-box (canopy options, recessed J-box) / SJ: conduit-cutout deep canopy for surface-mounted 4 in octagonal J-box (canopy options, surface-mounted 4 in octagonal J-box) |
| Emergency Backup | Optional (EM-H08170-LBF, emergency driver) / Optional (Optional emergency configuration) |
| Emergency Lumens | 640 lm (optional, at 8W, at 80 lm/W) |
| Indicator Light | Status indicator (canopy, optional emergency configuration) |
| Dimming | 0–10V |
| Minimum Dimming Level | 10% |
| Wattage Selectable | 4 in: Yes |
| Location Rating | Indoor / Damp location |
| Warranty | 5 years |
| Listings | cULus / cULus (damp location) |
| Family | Downlight |
Description
These modular architectural cylinders bring a slender, consistent look to suspended lighting in commercial interiors, with housing and trim options to suit a range of finishes. The cylinder comes in 4, 6 or 8 inch sizes and hangs by cable or pendant stem.
A COB LED source gives CRI 80+, with beam angles of 15°, 24°, 36° or 60° and color temperature at 2700K, 3000K, 3500K or 4000K. Wattage is selectable at 12, 18 or 25W. It dims with 0–10V controls down to 10% and runs on 120–277V, and an emergency driver is available as an option. Standard finishes are white or black powder coat, with custom colours offered. The fixture is rated for damp locations and operates from -20 to 40 °C.
cULus listed, with a 5-year warranty on parts and components.
Specifications
| General | |
|---|---|
| Family | Downlight |
| Light Source | COB LED |
| Size | 4 / 6 / 8 in |
| Light | |
|---|---|
| Beam Angle | 15° (narrow) / 24° (medium) / 36° (wide) / 60° (flood) |
| CCT | 2700 / 3000 / 3500 / 4000K |
| CRI | 80+ (standard) |
| Electrical | |
|---|---|
| Power Factor | 0.9+ |
| THD | up to 20% |
| Voltage | 120–277V |
| Wattage | 4 in: 12 / 18 / 25W |
| Compatibility | Lutron Diva-Dvtv (dimmers, Diva-Dvtv) / Leviton IP-710-DL (dimmers, IP-710-DL) |
| Physical | |
|---|---|
| Ambient Temperature | -20–40 °C (operating) |
| Coating | Powder coating |
| Finish | White / Black / Custom color |
| Mounting | Cable suspended / Pendant stem / 4 in: Cable suspended / 6 in / 8 in: Cable suspended |
| Fits | RJ: flat canopy for recessed J-box (canopy options, recessed J-box) / SJ: conduit-cutout deep canopy for surface-mounted 4 in octagonal J-box (canopy options, surface-mounted 4 in octagonal J-box) |
| Emergency | |
|---|---|
| Emergency Backup | Optional (EM-H08170-LBF, emergency driver) / Optional (Optional emergency configuration) |
| Emergency Lumens | 640 lm (optional, at 8W, at 80 lm/W) |
| Indicator Light | Status indicator (canopy, optional emergency configuration) |
| Controls | |
|---|---|
| Dimming Type | 0–10V |
| Minimum Dimming Level | 10% |
| Wattage Selectable | 4 in: Yes |
| Warranty | |
|---|---|
| Warranty | 5 years |
| Certifications | cULus (damp location) / cULus |
| Location Rating | Indoor / Damp location |
