MFD08 60W to 100W LED Flood Light

24/36/40/48/60/80/100W Wattage Selectable, Up to 14,000 Lumens
3000K/4000K/5000K CCT Selectable
120-277 or 347-480 Volt
Wet Location
Dark Bronze / Black / White Finish

📄 Download Spec Sheet (PDF)

Specifications

Wattage	60W model: 24 / 36 / 48 / 60W; 100W model: 40 / 60 / 80 / 100W
Voltage	120-277V, 347-480V
Dimming	0-10V
CCT	3000K / 4000K / 5000K
CRI	> 70
Lumens	100W model, 100%: 13,000 lm (at 3000K) / 14,000 lm (at 4000K) / 13,500 lm (at 5000K); 100W model, 80%, 80W: 10,800 lm (at 3000K) / 11,600 lm (at 4000K) / 11,200 lm (at 5000K); 100W model, 60%, 60W: 8,400 lm (at 3000K) / 9,000 lm (at 4000K) / 8,700 lm (at 5000K); 100W model, 40%, 40W: 5,800 lm (at 3000K) / 6,200 lm (at 4000K) / 6,000 lm (at 5000K); 60W model, 100%: 7,800 lm (at 3000K) / 8,400 lm (at 4000K) / 8,100 lm (at 5000K); 60W model, 80%, 48W: 6,480 lm (at 3000K) / 7,000 lm (at 4000K) / 6,700 lm (at 5000K); 60W model, 60%, 36W: 5,050 lm (at 3000K) / 5,400 lm (at 4000K) / 5,250 lm (at 5000K); 60W model, 40%, 24W: 3,480 lm (at 3000K) / 3,720 lm (at 4000K) / 3,600 lm (at 5000K)
Lifespan	50,000 hours
Dimensions	281 × 154.5 × 124.5 mm (11.06" × 6.06" 4.90")
Listings	DLC Premium / wet location: UL / cUL
Warranty	5-Year Manufacturer's Warranty
NEMA Distribution	7H × 6V (at 60W model, 100W model)
Efficacy	100W model, 100%: 130 lm/W (at 3000K) / 140 lm/W (at 4000K) / 135 lm/W (at 5000K); 100W model, 80%, 80W: 135 lm/W (at 3000K) / 146 lm/W (at 4000K) / 140 lm/W (at 5000K); 100W model, 60%, 60W: 140 lm/W (at 3000K) / 150 lm/W (at 4000K) / 145 lm/W (at 5000K); 100W model, 40%, 40W: 145 lm/W (at 3000K) / 155 lm/W (at 4000K) / 150 lm/W (at 5000K); 60W model, 100%: 130 lm/W (at 3000K) / 140 lm/W (at 4000K) / 135 lm/W (at 5000K); 60W model, 80%, 48W: 135 lm/W (at 3000K) / 146 lm/W (at 4000K) / 140 lm/W (at 5000K); 60W model, 60%, 36W: 140 lm/W (at 3000K) / 150 lm/W (at 4000K) / 146 lm/W (at 5000K); 60W model, 40%, 24W: 145 lm/W (at 3000K) / 155 lm/W (at 4000K) / 150 lm/W (at 5000K)
Power Factor	0.9+
THD	up to 20%
Current	60W model, 60W nominal: 0.5A (at 120V) / 0.29A (at 208V) / 0.25A (at 240V) / 0.22A (at 277V); 60W model, 60W nominal, high-voltage configuration: 0.29A (at 347V) / 0.21A (at 480V); 100W model, 100W nominal: 0.83A (at 120V) / 0.48A (at 208V) / 0.42A (at 240V) / 0.36A (at 277V); 100W model, 100W nominal, high-voltage configuration: 0.17A (at 347V) / 0.13A (at 480V)
Ambient Temperature	-40–40 °C (operating)
Color	Dark bronze / Black / White
Mounting	60W model: Knuckle / Trunnion; 100W model: Slip fitter / Yoke
Weight	60W knuckle: 3.152 lb (net) / 60W trunnion: 3.748 lb (net) / 100W slipfitter: 10.163 lb (net) / 100W yoke: 9.237 lb (net)
CCT Selectable	colour-adjustable versions: Yes, switchable
Photocell	Optional (field-installed or factory-installed by request)
Location Rating	Wet location
Family	Flood light
Series	MFD08 flood light

Categories: Area Pole Light, Area Pole Light, Outdoor LED Lighting Tag: 600W Flood light

Request A Quote

Description

The MFD08 is a low-profile LED flood light for parking lots, walkways, campuses, car dealerships, office complexes and internal roadways. It comes as a 60W model, selectable at 60, 48, 36 or 24W, or a 100W model, selectable at 100, 80, 60 or 40W, with color temperature selectable at 3000K, 4000K or 5000K. Output reaches up to 9,000 lumens on the 60W model and up to 14,000 lumens on the 100W model, through a 7H × 6V NEMA distribution with CRI 70.

It dims with 0–10V controls and runs on 120–277V, with 347–480V available. The wet-location rated fixture operates from -40°C to 40°C, comes in dark bronze, black or white, and mounts by knuckle, trunnion, slip fitter or yoke depending on the model. A photocell can be added in the field or factory-installed by request.

UL/cUL and DLC Premium listed, with a 50,000-hour rated life and a 5-year limited warranty.

Specifications

General
Family	Flood light
Series	MFD08 flood light

Light
CCT	colour-adjustable versions: 3000 / 4000 / 5000K
CRI	70
NEMA Distribution	7H × 6V (at 60W model, 100W model)
Efficacy	100W model, 100%: 130 lm/W (at 3000K) / 140 lm/W (at 4000K) / 135 lm/W (at 5000K); 100W model, 80%, 80W: 135 lm/W (at 3000K) / 146 lm/W (at 4000K) / 140 lm/W (at 5000K); 100W model, 60%, 60W: 140 lm/W (at 3000K) / 150 lm/W (at 4000K) / 145 lm/W (at 5000K); 100W model, 40%, 40W: 145 lm/W (at 3000K) / 155 lm/W (at 4000K) / 150 lm/W (at 5000K); 60W model, 100%: 130 lm/W (at 3000K) / 140 lm/W (at 4000K) / 135 lm/W (at 5000K); 60W model, 80%, 48W: 135 lm/W (at 3000K) / 146 lm/W (at 4000K) / 140 lm/W (at 5000K); 60W model, 60%, 36W: 140 lm/W (at 3000K) / 150 lm/W (at 4000K) / 146 lm/W (at 5000K); 60W model, 40%, 24W: 145 lm/W (at 3000K) / 155 lm/W (at 4000K) / 150 lm/W (at 5000K)
Lumens	100W model, 100%: 13,000 lm (at 3000K) / 14,000 lm (at 4000K) / 13,500 lm (at 5000K); 100W model, 80%, 80W: 10,800 lm (at 3000K) / 11,600 lm (at 4000K) / 11,200 lm (at 5000K); 100W model, 60%, 60W: 8,400 lm (at 3000K) / 9,000 lm (at 4000K) / 8,700 lm (at 5000K); 100W model, 40%, 40W: 5,800 lm (at 3000K) / 6,200 lm (at 4000K) / 6,000 lm (at 5000K); 60W model, 100%: 7,800 lm (at 3000K) / 8,400 lm (at 4000K) / 8,100 lm (at 5000K); 60W model, 80%, 48W: 6,480 lm (at 3000K) / 7,000 lm (at 4000K) / 6,700 lm (at 5000K); 60W model, 60%, 36W: 5,050 lm (at 3000K) / 5,400 lm (at 4000K) / 5,250 lm (at 5000K); 60W model, 40%, 24W: 3,480 lm (at 3000K) / 3,720 lm (at 4000K) / 3,600 lm (at 5000K)

Electrical
Power Factor	0.9+
THD	up to 20%
Voltage	120–277V / 347–480V
Wattage	60W model: 24 / 36 / 48 / 60W; 100W model: 40 / 60 / 80 / 100W
Current	60W model, 60W nominal: 0.5A (at 120V) / 0.29A (at 208V) / 0.25A (at 240V) / 0.22A (at 277V); 60W model, 60W nominal, high-voltage configuration: 0.29A (at 347V) / 0.21A (at 480V); 100W model, 100W nominal: 0.83A (at 120V) / 0.48A (at 208V) / 0.42A (at 240V) / 0.36A (at 277V); 100W model, 100W nominal, high-voltage configuration: 0.17A (at 347V) / 0.13A (at 480V)

Physical
Ambient Temperature	-40–40 °C (operating)
Finish	Dark bronze / Black / White
Mounting	60W model: Knuckle / Trunnion; 100W model: Slip fitter / Yoke
Weight	60W knuckle: 3.152 lb (net) / 60W trunnion: 3.748 lb (net) / 100W slipfitter: 10.163 lb (net) / 100W yoke: 9.237 lb (net)
