LED Flat Panel 2X2 with Pre-wired Emergency Battery Backup
LED Flat Panel 2X2 with Pre-wired Emergency Battery Backup
Model: E2-BPL-2X2-15/20/25/30/40W-35/40/50/57/65K-E
15/20/25/30/40W Wattage Selectable, Up to 5,000 Lumens
3500K/4000K/5000K/5700K/6500K CCT Selectable
Built-in 8W Emergency Battery, 90 Minutes
0-10V Dimmable
100-277 Volt
Specifications
| Wattage | 15 / 20 / 25 / 30 / 40W |
| Voltage | 100-277V |
| Dimming | 0-10V |
| CCT | 3500K / 4000K / 5000K / 5700K / 6500K |
| CRI | > 80 |
| Lumens | 1875 lm / 2500 lm / 3125 lm / 3750 lm / 5000 lm |
| Lifespan | 50,000 hours (at L70) |
| Listings | DLC Premium / UL |
| Warranty | 5-Year Manufacturer's Warranty |
| Size | 2×2 ft |
| Efficacy | 125 lm/W |
| Power Factor | 0.92 |
| Ambient Temperature | -4–122 °F (working) |
| Dimensions | 23.7 × 23.7 × 1.5 in |
| Mounting | Grid lay-in |
| Weight | 6 lb (net) |
| Emergency Lumens | 1,000 lm |
| Emergency Power | 8W |
| Emergency Runtime | 90 minutes |
| Indicator Light | Push-button indicator |
| Test Switch | Push-button indicator (push button, manual) |
| CCT Selectable | Yes, switchable |
| Dimmable | Yes |
| Wattage Selectable | Yes |
| Standards | RoHS |
| Family | Troffer and flat panel |
| Series | Back-lit flat panel (BPL) |
Description
This versatile 2×2 LED panel has an 8W emergency battery pre-wired inside, providing 1,000 lumens for 90 minutes during a power outage, with a push-button indicator on the fixture. Choose a wattage of 15, 20, 25, 30 or 40W to set the brightness, and a color temperature of 3500K, 4000K, 5000K, 5700K or 6500K for warm white, cool white or daylight tones.
The panel delivers 125 lm/W with CRI 80+, dims on 0–10V controls and runs on 100–277V. It measures 23.7 × 23.7 × 1.5 in and lays into drop ceilings for ambient light in offices, schools and healthcare facilities.
UL and DLC Premium listed, with a 50,000-hour rated life and a 5-year warranty.
Specifications
| General | |
|---|---|
| Family | Troffer and flat panel |
| Series | Back-lit flat panel (BPL) |
| Size | 2×2 ft |
| Light | |
|---|---|
| CCT | 3500 / 4000 / 5000 / 5700 / 6500K |
| CRI | 80+ |
| Efficacy | 125 lm/W |
| Lumens | 1,875 / 2,500 / 3,125 / 3,750 / 5,000 lm |
| Electrical | |
|---|---|
| Power Factor | 0.92 |
| Voltage | 100–277V |
| Wattage | 15 / 20 / 25 / 30 / 40W |
| Physical | |
|---|---|
| Ambient Temperature | -4–122 °F (working) |
| Dimensions | 23.7 × 23.7 × 1.5 in |
| Mounting | Grid lay-in |
| Weight | 6 lb (net) |
| Emergency | |
|---|---|
| Emergency Lumens | 1,000 lm |
| Emergency Power | 8W |
| Emergency Runtime | 90 minutes |
| Indicator Light | Push-button indicator |
| Controls | |
|---|---|
| CCT Selectable | Yes, switchable |
| Dimmable | Yes |
| Dimming Type | 0–10V |
| Wattage Selectable | Yes |
| Warranty | |
|---|---|
| Rated Life | 50,000 hours (at L70) |
| Warranty | 5 years |
| Certifications | UL / DLC Premium |
| Standards | RoHS |
