4FT Wide LED Linear Strip With Emergency Battery Backup
4FT Wide LED Linear Strip With Emergency Battery Backup
Model: E2-LS-WIDE-4FT-24/40W-35/40/50K-E
36/40W Wattage Selectable, Up to 5,000 Lumens
3500K/4000K/5000K CCT Selectable
Built-in Emergency Battery
0-10V Dimmable
100-277 Volt
Specifications
| Wattage | 36W / 40W / 36W (at 4500 lm) / 40W (at 5000 lm) |
| Voltage | 100–277V |
| Dimming | 0-10V |
| CCT | 3500K / 4000K / 5000K |
| CRI | > 80 |
| Lumens | 4,500 lm (at 36W) / 5,000 lm (at 40W) |
| Lifespan | 50,000 hours (at L70) |
| Dimensions | 1206 ×115 × 91 mm (48" × 4.53" × 3.58") |
| Listings | DLC Premium / UL |
| Warranty | 5-Year Manufacturer's Warranty |
| Size | 4 ft |
| Power Factor | 0.9+ |
| Ambient Temperature | -22–140 °F (storage) / -4–113 °F (working) |
| Knockouts | 8 |
| Mounting | Surface / Chain suspended |
| Emergency Backup | Integrated (E) |
| Emergency Power | 8W (emergency option) |
| Wattage Selectable | Yes |
| Standards | RoHS |
| Family | Linear strip and wraparound |
| Series | Wide linear strip |
Description
Ideal for indoor commercial applications, this 4-foot wide-body LED linear strip comes with an emergency battery installed and replaces T12 and T8 strip fixtures in healthcare facilities, educational institutions, corporate offices, retail stores, hospitality venues, warehouses, grocery markets and more, including corridors. When the power fails, the battery provides 1.5 hours of 8W backup lighting.
Wattage is selectable at 36 or 40W, giving 4,500 or 5,000 lumens, and color temperature at 3500K, 4000K or 5000K, set by switches at the fixture. It dims with 0–10V controls and runs on 100–277V. Surface or chain-suspended mounting and 8 knockout locations give installation flexibility.
UL and DLC Premium listed and RoHS compliant, with a 50,000-hour rated life and a 5-year warranty.
Specifications
| General | |
|---|---|
| Family | Linear strip and wraparound |
| Series | Wide linear strip |
| Size | 4 ft |
| Light | |
|---|---|
| CCT | 3500 / 4000 / 5000K |
| CRI | 80+ |
| Lumens | 4,500 lm (at 36W) / 5,000 lm (at 40W) |
| Electrical | |
|---|---|
| Power Factor | 0.9+ |
| Voltage | 100–277V |
| Wattage | 36W / 40W / 36W (at 4500 lm) / 40W (at 5000 lm) |
| Physical | |
|---|---|
| Ambient Temperature | -22–140 °F (storage) / -4–113 °F (working) |
| Dimensions | 1,206 × 115 × 91 mm |
| Knockouts | 8 |
| Mounting | Surface / Chain suspended |
| Emergency | |
|---|---|
| Emergency Backup | Integrated (E) |
| Emergency Power | 8W (emergency option) |
| Controls | |
|---|---|
| Dimming Type | 0–10V |
| Wattage Selectable | Yes |
| Warranty | |
|---|---|
| Rated Life | 50,000 hours (at L70) |
| Warranty | 5 years |
| Certifications | UL / DLC Premium |
| Standards | RoHS |
