LED Flat Panel 2X4 with Pre-wired Emergency Battery Backup
LED Flat Panel 2X4 with Pre-wired Emergency Battery Backup
Model: E2-BPL-2X4-304050W-354050K-E
30/40/50W Wattage Selectable, Up to 6,000 Lumens
3500K/4000K/5000K CCT Selectable
Built-in 8W Emergency Battery, 90+ Minutes
0-10V Dimmable
120-277 Volt
Specifications
| Wattage | 30W / 40W / 50W |
| Voltage | 120-277V |
| Dimming | 0-10V |
| CCT | 3500K / 4000K / 5000K |
| CRI | > 80 |
| Lumens | 4445 lm / 5080 lm / 6000 lm |
| Lifespan | 50,000 hours (at L70) |
| Listings | DLC Premium / UL |
| Warranty | 5-Year Manufacturer's Warranty |
| Size | 2×4 ft |
| Efficacy | 127 lm/W |
| Power Factor | 0.92 |
| Ambient Temperature | -4–122 °F (working) |
| Dimensions | 47.75 × 23.75 × 1.8 in |
| Mounting | Grid lay-in |
| Weight | 7 lb (net) |
| Emergency Backup | Integrated |
| Emergency Power | 8W |
| Emergency Runtime | 90+ minutes |
| CCT Selectable | Yes, switchable |
| Dimmable | Yes |
| Wattage Selectable | Yes |
| Standards | RoHS |
| Family | Troffer and flat panel |
| Series | Back-lit flat panel (BPL) |
Description
A 2×4 LED panel with the emergency battery pre-wired at the factory, so there's no aftermarket battery to install or match to the driver. During a power outage it provides 90+ minutes of 8W battery power, and an indicator with a test button on the face of the panel shows battery status.
Wattage is selectable at 30, 40 or 50W, giving 4,445, 5,080 or 6,000 lumens, and color temperature at 3500K, 4000K or 5000K, in any combination. It dims with 0–10V controls, runs on 120–277V and lays into a standard ceiling grid.
DLC Premium and UL listed, with a 50,000-hour rated life and a 5-year warranty.
Specifications
| General | |
|---|---|
| Family | Troffer and flat panel |
| Series | Back-lit flat panel (BPL) |
| Size | 2×4 ft |
| Light | |
|---|---|
| CCT | 3500 / 4000 / 5000K |
| CRI | 80+ |
| Efficacy | 127 lm/W |
| Lumens | 4,445 / 5,080 / 6,000 lm |
| Electrical | |
|---|---|
| Power Factor | 0.92 |
| Voltage | 120–277V |
| Wattage | 30 / 40 / 50W |
| Physical | |
|---|---|
| Ambient Temperature | -4–122 °F (working) |
| Dimensions | 47.75 × 23.75 × 1.8 in |
| Mounting | Grid lay-in |
| Weight | 7 lb (net) |
| Emergency | |
|---|---|
| Emergency Backup | Integrated |
| Emergency Power | 8W |
| Emergency Runtime | 90+ minutes |
| Controls | |
|---|---|
| CCT Selectable | Yes, switchable |
| Dimmable | Yes |
| Dimming Type | 0–10V |
| Wattage Selectable | Yes |
| Warranty | |
|---|---|
| Rated Life | 50,000 hours (at L70) |
| Warranty | 5 years |
| Certifications | UL / DLC Premium |
| Standards | RoHS |
