2FT Standard Linear Strip With Emergency Battery Backup
2FT Standard Linear Strip With Emergency Battery Backup
Model: E2-LS-STD-2FT-10/12/15/2/26W-30/35/40/50/65K-E
15/20/24W Wattage Selectable, 3,120 Lumens
3500K/4000K/5000K CCT Selectable
Built-in Emergency Battery
0-10V Dimmable
100-277 Volt
Specifications
| Wattage | 15W / 20W / 24W |
| Voltage | 100–277V |
| Dimming | 0-10V |
| CCT | 3500K / 4000K / 5000K |
| CRI | > 80 |
| Lumens | 1950 lm / 2600 lm / 3120 lm |
| Lifespan | 50,000 hours (at L70) |
| Dimensions | 609 ×75 × 83 mm (23.97" ×2.95" × 3.26") |
| Listings | DLC Premium / ETL / cETLus |
| Warranty | 5-Year Manufacturer's Warranty |
| Size | 2 ft |
| Beam Angle | 120° |
| Efficacy | 130 lm/W |
| Power Factor | 0.9+ |
| Ambient Temperature | -4–113 °F (operating) / -22–140 °F (storage) |
| Mounting | Surface / Chain suspended |
| Emergency Backup | Integrated |
| CCT Selectable | Yes, switchable |
| Motion Sensor | Optional (microwave, on request, external or built-in) |
| Wattage Selectable | Yes |
| Standards | CE / RoHS |
| Family | Linear strip and wraparound |
| Series | Standard-width linear strip |
Description
Ideal for indoor applications, this 2-foot standard-width LED linear strip comes with an emergency battery installed and provides task and general lighting in healthcare facilities, educational institutions, corporate offices, retail stores, hospitality venues, warehouses, grocery markets and more, as well as storage and utility buildings, workshops and garages. When the power fails, the battery keeps it lit for 1.5 hours. Integrated switches set wattage and color temperature, and a smooth lens spreads light evenly.
Wattage is selectable at 15, 20 or 24W for up to 3,120 lumens at 130 lm/W, and color temperature at 3500K, 4000K or 5000K, over a 120° beam. It dims with 0–10V controls, runs on 100–277V and mounts to a surface or on chains, and a microwave motion sensor is available on request.
ETL, cETLus and DLC Premium listed and CE and RoHS compliant, with a 50,000-hour rated life and a 5-year warranty.
Specifications
| General | |
|---|---|
| Family | Linear strip and wraparound |
| Series | Standard-width linear strip |
| Size | 2 ft |
| Light | |
|---|---|
| Beam Angle | 120° |
| CCT | 3500 / 4000 / 5000K |
| CRI | 80+ |
| Efficacy | 130 lm/W |
| Lumens | 3,120 lm |
| Electrical | |
|---|---|
| Power Factor | 0.9+ |
| Voltage | 100–277V |
| Wattage | 15 / 20 / 24W |
| Physical | |
|---|---|
| Ambient Temperature | -4–113 °F (operating) / -22–140 °F (storage) |
| Dimensions | 609 × 75 × 83 mm |
| Mounting | Surface / Chain suspended |
| Emergency | |
|---|---|
| Emergency Backup | Integrated |
| Controls | |
|---|---|
| CCT Selectable | Yes, switchable |
| Dimming Type | 0–10V |
| Motion Sensor | Optional (microwave, on request, external or built-in) |
| Wattage Selectable | Yes |
| Warranty | |
|---|---|
| Rated Life | 50,000 hours (at L70) |
| Warranty | 5 years |
| Certifications | ETL / cETLus / DLC Premium |
| Standards | CE / RoHS |
