300W G4 Area Light
300W G4 Area Light
Model: E2-SB-G4-300W-50K
300W, 45,000 Lumens
5000K CCT
Type III/V Distribution
IP65
Specifications
| Wattage | 300W |
| Voltage | 100-277V, 180-480V |
| CCT | 3000K / 4000K / 5000K |
| CRI | 75.4 |
| Lumens | 45000 lm |
| Lifespan | 100,000 hours (at L70) |
| Dimensions | 200W/300W configuration: 785 × 376 × 101 mm |
| Listings | ETL / IP65 |
| Warranty | 5-Year Manufacturer's Warranty |
| Distribution Type | Type III / Type V |
| Frequency | 50–60 Hz |
| Power Factor | 0.9+ |
| THD | up to 20% |
| Adjustable Aiming | Yes (fitter mount) / Yes (adjustable fitter mount) |
| Ambient Temperature | -40–122 °F (working) |
| Coating | Powder coating |
| Color | Dark bronze |
| Mounting | Slip fitter (fitter mount) |
| Motion Sensor | Optional |
| Photocell | Optional (optional) |
| Mercury Free | Yes |
| Standards | RoHS |
| Family | Area and roadway light |
| Series | G4 area light |
Description
A 300W shoebox-style LED area light for parking lots, producing 45,000 lumens at 5000K. Type III or Type V distribution lets it cover a lot edge or the open middle of a lot.
It mounts on a slip fitter with an adjustable aiming angle, and the dark bronze powder-coated housing is IP65 rated for operation from -40 to 122°F. The fixture measures 785 × 376 × 101 mm, and motion sensor and photocell control are available as options.
ETL listed, RoHS compliant and mercury-free, with a 100,000-hour rated life and a 5-year limited warranty.
Specifications
| General | |
|---|---|
| Family | Area and roadway light |
| Series | G4 area light |
| Light | |
|---|---|
| CCT | 5000K |
| CRI | 75.4 |
| Distribution Type | Type III / Type V |
| Lumens | 45,000 lm |
| Electrical | |
|---|---|
| Frequency | 50–60 Hz |
| Power Factor | 0.9+ |
| THD | up to 20% |
| Wattage | 300W |
| Physical | |
|---|---|
| Adjustable Aiming | Yes (fitter mount) / Yes (adjustable fitter mount) |
| Ambient Temperature | -40–122 °F (working) |
| Coating | Powder coating |
| Dimensions | 200W/300W configuration: 785 × 376 × 101 mm |
| Finish | Dark bronze |
| Mounting | Slip fitter (fitter mount) |
| Controls | |
|---|---|
| Motion Sensor | Optional |
| Photocell | Optional (optional) |
| Warranty | |
|---|---|
| Rated Life | 100,000 hours (at L70) |
| Warranty | 5 years |
| Certifications | ETL |
| IP Rating | IP65 |
| Mercury Free | Yes |
| Standards | RoHS |
