G7 Area Light
G7 Area Light
48/80/100W Wattage Selectable
5000K CCT
Type III/IV/V Distribution
100-277 or 347 Volt
Specifications
| Wattage | 48W / 80W / 100W |
| Voltage | 100-277V, 347V |
| Dimming | 1–10V |
| CCT | 3000K / 4000K / 5000K |
| CRI | > 53 |
| Features | Tool-free safety switch |
| Listings | DLC Premium / cETLus |
| Distribution Type | Type III / Type IV / Type V |
| Warranty | 5-Year Manufacturer's Warranty |
| Frequency | 50–60 Hz |
| Ambient Temperature | -40–50 °C (operating) / -40–70 °C (storage) |
| Color | Dark bronze / Black / White |
| Mounting | Slip fitter / Square pole (arm) / Round pole (arm) / Trunnion |
| Self-Cleaning | Yes |
| Surface Finish | Smooth |
| Motion Sensor | Optional / Optional (PIR) |
| Photocell | Optional (option) / Optional (option, plug-in) |
| Wattage Selectable | Yes |
| Protection | Surge protection (surge) |
| Lifespan | 80,000+ hours (at 64°C) |
| Accessories | Shorting cap / DIP switch for four-wattage selection |
| Family | Area and roadway light |
| Series | G7 area light |
Description
The G7 Series is an LED area light for parking lots and outdoor sites, with wattage selectable at 48W, 80W or 100W and a 5000K color temperature at CRI 53+. It runs on 100–277V, with 347V available.
Slip fitter, square pole, round pole and trunnion mounts are offered, with dark bronze standard and black or white available. The body has a smooth, self-cleaning finish, and Type III, Type IV or Type V distribution is offered. Photocell and motion sensor options are available, and the fixture includes surge protection and a tool-free safety switch.
cETLus and DLC Premium listed, with an 80,000+ hour rated life and a 5-year warranty.
Specifications
| General | |
|---|---|
| Family | Area and roadway light |
| Series | G7 area light |
| Features | Tool-free safety switch |
| Light | |
|---|---|
| CCT | 5000K |
| CRI | 53+ |
| Distribution Type | Type III / Type IV / Type V |
| Electrical | |
|---|---|
| Frequency | 50–60 Hz |
| Voltage | 100–277V / 347V |
| Wattage | 48 / 80 / 100W |
| Physical | |
|---|---|
| Ambient Temperature | -40–50 °C (operating) / -40–70 °C (storage) |
| Finish | Dark bronze / Black / White |
| Mounting | Slip fitter / Square pole (arm) / Round pole (arm) / Trunnion |
| Self-Cleaning | Yes |
| Surface Finish | Smooth |
| Controls | |
|---|---|
| Dimming Type | 1–10V |
| Motion Sensor | Optional / Optional (PIR) |
| Photocell | Optional (option) / Optional (option, plug-in) |
| Wattage Selectable | Yes |
| Warranty | |
|---|---|
| Rated Life | 80,000+ hours (at 64°C) |
| Warranty | 5 years |
| Certifications | cETLus / DLC Premium |
| Protection | Surge protection (surge) |
| Accessories | Shorting cap / DIP switch for four-wattage selection |
