LED UFO High Bay 100W
LED UFO High Bay 100W
Model: E2-HB-UFO-100W-50K-120/277V
100W, 14,000 Lumens
2700K–6500K CCT Selectable
0-10V Dimmable
120-277 or 120-347 Volt
IP65
Specifications
| Wattage | 100W |
| Voltage | 120-277V / 120-347V |
| Dimming | 0-10V |
| CCT | 2700K / 6500K |
| CRI | > 80 |
| Lumens | 14,000 lm |
| Lifespan | 54,000 hours (at L70) |
| Listings | DLC Premium / IP65 / cULus |
| Warranty | 5-Year Manufacturer's Warranty |
| Light Source | LED |
| Beam Angle | 85° |
| Efficacy | 150 lm/W (±10%) |
| Glare Control | Lower UGR |
| Frequency | 50 / 60 Hz |
| Power Factor | 0.9+ |
| THD | up to 20% |
| Color | Black / White / Custom color |
| Mounting | Loop (ceiling) / Hook (ceiling) |
| Dimmable | Yes |
| Standards | CE |
| Accessories | Safety rope (optional) / Emergency driver (optional) |
| Family | High bay |
| Series | HB03 UFO high bay |
Description
A 100W LED UFO high bay for warehouses, gymnasiums and production and assembly areas, delivering 14,000 lumens at 150 lm/W. Its round housing hangs from a ceiling loop or hook, and an 85° beam with lower glare spreads light across high-ceiling spaces.
It is available in color temperatures from 2700K to 6500K with CRI 80+, dims with 0–10V controls and runs on 120–277V or 120–347V. The IP65-rated fixture comes in black, white or a custom color, with a safety rope and an emergency driver available as options.
cULus and DLC Premium listed, with a 54,000-hour rated life and a 5-year warranty.
Specifications
| General | |
|---|---|
| Family | High bay |
| Series | HB03 UFO high bay |
| Light Source | LED |
| Light | |
|---|---|
| Beam Angle | 85° |
| CCT | 2700–6500K |
| CRI | 80+ |
| Efficacy | 150 lm/W (±10%) |
| Glare Control | Lower UGR |
| Lumens | 14,000 lm |
| Electrical | |
|---|---|
| Frequency | 50 / 60 Hz |
| Power Factor | 0.9+ |
| THD | up to 20% |
| Voltage | 120–277V / 120–347V |
| Wattage | 100W |
| Physical | |
|---|---|
| Finish | Black / White / Custom color |
| Mounting | Loop (ceiling) / Hook (ceiling) |
| Controls | |
|---|---|
| Dimmable | Yes |
| Dimming Type | 0–10V |
| Warranty | |
|---|---|
| Rated Life | 54,000 hours (at L70) |
| Warranty | 5 years |
| Certifications | cULus / DLC Premium |
| IP Rating | IP65 |
| Standards | CE |
| Accessories | Safety rope (optional) / Emergency driver (optional) |
