Slim Down Lights 4 Inch 2 Hours Fire Rated
Slim Down Lights 4 Inch 2 Hours Fire Rated
9W
2700K/3000K/3500K/4000K/5000K CCT Selectable
TRIAC Dimmable
100-130 or 100-277 or 100-347 Volt
Specifications
| Wattage | 9W |
| Voltage | 100–130V / 100–277V / 100–347V |
| Dimming | TRIAC |
| CCT | 2700 / 3000 / 3500 / 4000 / 5000K |
| CRI | > 90 |
| Lifespan | 50,000 hours |
| Dimensions | 125 × 24 mm (4.75" × 1") |
| Listings | cETLus |
| Warranty | 5-Year Manufacturer's Warranty |
| Size | 4 in |
| Cutout | 105 mm |
| Diameter | 125 mm |
| Height | 24 mm |
| Material | Metal (clips, wire connector) |
| Mounting | Spring clips |
| CCT Selectable | Yes, switchable |
| Dimmable | Yes |
| Air-Tight | Yes |
| Fire Rating | up to 2 hours |
| Flame Retardant | Metal fireproof paint / Fireproof cotton / Metal clips / Metal wire connector |
| IC Rating | Yes |
| Standards | FCC / RoHS |
| Family | Downlight |
| Series | Ultra Slim Downlight (SLIM, SLIM-E) |
Description
This 4-inch fire-rated ultra-thin downlight carries up to a 2-hour fire rating and installs without additional housing, suiting tight ceiling spaces in residential and commercial settings. It is Type IC and air-tight rated, with fireproof paint and fireproof cotton in its construction.
It draws 9W, with color temperature selectable at 2700K, 3000K, 3500K, 4000K or 5000K and CRI 90+, and is TRIAC dimmable. It is offered for 100–130V, 100–277V or 100–347V input. Spring clips secure it in a 105 mm cutout, and plenum-rated cable suits commercial installations. The fixture is 125 mm across and 24 mm tall.
cETLus listed, with a 50,000-hour rated life and a 5-year warranty.
Specifications
| General | |
|---|---|
| Family | Downlight |
| Series | Ultra Slim Downlight (SLIM, SLIM-E) |
| Size | 4 in |
| Light | |
|---|---|
| CCT | 2700 / 3000 / 3500 / 4000 / 5000K |
| CRI | 90+ |
| Electrical | |
|---|---|
| Voltage | 100–130V / 100–277V / 100–347V |
| Wattage | 9W |
| Physical | |
|---|---|
| Cutout | 105 mm |
| Diameter | 125 mm |
| Height | 24 mm |
| Material | Metal (clips, wire connector) |
| Mounting | Spring clips |
| Controls | |
|---|---|
| CCT Selectable | Yes, switchable |
| Dimmable | Yes |
| Dimming Type | TRIAC |
| Warranty | |
|---|---|
| Rated Life | 50,000 hours |
| Warranty | 5 years |
| Air-Tight | Yes |
| Certifications | cETLus |
| Fire Rating | up to 2 hours |
| Flame Retardant | Metal fireproof paint / Fireproof cotton / Metal clips / Metal wire connector |
| IC Rating | Yes |
| Standards | FCC / RoHS |
