2FT Slim LED Linear Strip
2FT Slim LED Linear Strip
Model: E2-LS-SLIM-2FT-18/24W-35/40/50K
18/24W Wattage Selectable, 3,120 Lumens
3500K/4000K/5000K CCT Selectable
0-10V Dimmable
100-277 Volt
Specifications
| Wattage | 18W / 24W |
| Voltage | 100–277V |
| Dimming | 0-10V |
| CCT | 3500K / 4000K / 5000K |
| CRI | 80+ |
| Lumens | 3,120 lm (at 2-ft model) |
| Lifespan | 50,000 hours |
| Dimensions | 606 × 60 × 82 mm (23.86" × 2.36" × 3.23") |
| Listings | DLC Premium / UL |
| Warranty | 5-Year Manufacturer's Warranty |
| Size | 2 ft |
| Efficacy | 130 lm/W |
| Power Factor | 0.9+ |
| Ambient Temperature | -4–113 °F (working) / -22–140 °F (storage) |
| Mounting | Surface / Chain suspended |
| Emergency Backup | Not included |
| CCT Selectable | Yes, switchable |
| Motion Sensor | Not included |
| Wattage Selectable | Yes |
| Standards | RoHS |
| Family | Linear strip and wraparound |
| Series | Slim linear strip |
Description
Ideal for indoor applications, this slim 2-foot LED linear strip replaces T8 and T12 strip fixtures in healthcare facilities, educational institutions, corporate offices, retail stores, hospitality venues, warehouses, grocery markets and more, including schools and supermarkets. Selectable wattage and color temperature let installers adapt the lighting to the space.
Wattage is selectable at 18 or 24W for up to 3,120 lumens at 130 lm/W, and color temperature at 3500K, 4000K or 5000K. It dims with 0–10V controls, runs on 100–277V and mounts to a surface or on chains.
UL and DLC Premium listed and RoHS compliant, with a 50,000-hour rated life and a 5-year warranty.
Specifications
| General | |
|---|---|
| Family | Linear strip and wraparound |
| Series | Slim linear strip |
| Size | 2 ft |
| Light | |
|---|---|
| CCT | 3500 / 4000 / 5000K |
| CRI | 80+ |
| Efficacy | 130 lm/W |
| Lumens | 3,120 lm (at 2-ft model) |
| Electrical | |
|---|---|
| Power Factor | 0.9+ |
| Voltage | 100–277V |
| Wattage | 18 / 24W |
| Physical | |
|---|---|
| Ambient Temperature | -4–113 °F (working) / -22–140 °F (storage) |
| Dimensions | 606 × 60 × 82 mm |
| Mounting | Surface / Chain suspended |
| Emergency | |
|---|---|
| Emergency Backup | Not included |
| Controls | |
|---|---|
| CCT Selectable | Yes, switchable |
| Dimming Type | 0–10V |
| Motion Sensor | Not included |
| Wattage Selectable | Yes |
| Warranty | |
|---|---|
| Rated Life | 50,000 hours |
| Warranty | 5 years |
| Certifications | UL / DLC Premium |
| Standards | RoHS |
