E2-ST Series Solar Street Light
E2-ST Series Solar Street Light
18/72W Wattage Selectable, Up to 10,000 Lumens
3000K–6000K CCT Selectable
Integrated Motion Sensor
IP65
Specifications
| Wattage | 18W - 72W |
| Dimming | Available |
| CCT | 3000K - 6000K |
| CRI | 83 |
| Lumens | 2,000 lm (at E2-ST2) / 3,000 lm (at E2-ST3) / 4,000 lm (at E2-ST4) / 5,000 lm (at E2-ST5) / 6,000 lm (at E2-ST6) / 7,000 lm (at E2-ST7) / 8,000 lm (at E2-ST8) / 9,000 lm (at E2-ST9) / 10,000 lm (at E2-ST10) |
| Dimensions | E2-ST2: 678 × 303 × 84 mm / E2-ST3: 812 × 303 × 84 mm / E2-ST4: 963 × 303 × 84 mm / E2-ST5: 1,326 × 303 × 84 mm / E2-ST6: 1,095 × 381 × 84 mm / E2-ST7: 1,326 × 381 × 84 mm / E2-ST8: 1,563 × 381 × 84 mm / E2-ST9: 1,563 × 381 × 84 mm / E2-ST10: 1,563 × 381 × 84 mm |
| Mounting Height | E2-ST2: 2–3 m / E2-ST3: 3–4 m / E2-ST4: 4–6 m / E2-ST5: 4–6 m / E2-ST6: 5–7 m / E2-ST7: 5–7 m / E2-ST8: 6–8 m / E2-ST9: 6–8 m / E2-ST10: 6–8 m |
| Weight | E2-ST2: 36 lb / E2-ST3: 36 lb / E2-ST4: 41 lb / E2-ST5: 56 lb / E2-ST6: 65 lb / E2-ST7: 65 lb / E2-ST8: 87 lb / E2-ST9: 87 lb / E2-ST10: 89 lb |
| Warranty | 3 years |
| Battery Serviceability | Yes |
| Recharge Time | 10 hours |
| Emergency Runtime | 7 nights |
| Dimmable | Yes (bi-level motion dimming) |
| Motion Sensor | Integrated (PIR) |
| Power Source | Solar / Battery |
| Sensor Type | Passive infrared (PIR) |
| Control Functions | lighting mode M1 (30% brightness + PIR until dawn, M1) / lighting mode M2 (5 hours at 100% brightness + 5 hours PIR with 25% dim light + 70% brightness until dawn, M2) / lighting mode M3 (70% brightness until dawn, M3) |
| Battery Cycle Life | 1,500 |
| Listings | IP65 |
| Family | Solar luminaire |
Description
This premium LED solar street light is well suited to surface streets, service roads, parking lots, parks, bus stops, crosswalks and walking or cycling paths, with no utility wiring or trenching. Its all-in-one design integrates the battery, LEDs and solar panel, and the detachable components and replaceable lithium-ion battery keep it serviceable.
Nine models deliver 2,000 to 10,000 lumens, in 3000–6000K with a CRI of 83, for mounting heights from 2–3 m up to 6–8 m. A built-in PIR motion sensor drives motion dimming, with M1, M2 and M3 lighting modes. The battery is rated for 1,500 cycles, recharges in 10 hours and runs for 7 nights.
The aluminum alloy housing is rated IP65, the LEDs are rated for 50,000 hours, and it carries a 3-year warranty.
Specifications
| General | |
|---|---|
| Family | Solar luminaire |
| Light | |
|---|---|
| CCT | 3000–6000K |
| CRI | 83 |
| Lumens | 2,000 lm (at E2-ST2) / 3,000 lm (at E2-ST3) / 4,000 lm (at E2-ST4) / 5,000 lm (at E2-ST5) / 6,000 lm (at E2-ST6) / 7,000 lm (at E2-ST7) / 8,000 lm (at E2-ST8) / 9,000 lm (at E2-ST9) / 10,000 lm (at E2-ST10) |
| Electrical | |
|---|---|
| Wattage | 18–72W |
| Physical | |
|---|---|
| Dimensions | E2-ST2: 678 × 303 × 84 mm / E2-ST3: 812 × 303 × 84 mm / E2-ST4: 963 × 303 × 84 mm / E2-ST5: 1,326 × 303 × 84 mm / E2-ST6: 1,095 × 381 × 84 mm / E2-ST7: 1,326 × 381 × 84 mm / E2-ST8: 1,563 × 381 × 84 mm / E2-ST9: 1,563 × 381 × 84 mm / E2-ST10: 1,563 × 381 × 84 mm |
| Mounting Height | E2-ST2: 2–3 m / E2-ST3: 3–4 m / E2-ST4: 4–6 m / E2-ST5: 4–6 m / E2-ST6: 5–7 m / E2-ST7: 5–7 m / E2-ST8: 6–8 m / E2-ST9: 6–8 m / E2-ST10: 6–8 m |
| Weight | E2-ST2: 36 lb / E2-ST3: 36 lb / E2-ST4: 41 lb / E2-ST5: 56 lb / E2-ST6: 65 lb / E2-ST7: 65 lb / E2-ST8: 87 lb / E2-ST9: 87 lb / E2-ST10: 89 lb |
| Solar | |
|---|---|
| Battery Serviceability | Yes |
| Charge Time | 10 hours |
| Runtime | 7 nights |
| Controls | |
|---|---|
| Dimmable | Yes (bi-level motion dimming) |
| Motion Sensor | Integrated (PIR) |
| Power Source | Solar / Battery |
| Sensor Type | Passive infrared (PIR) |
| Control Functions | lighting mode M1 (30% brightness + PIR until dawn, M1) / lighting mode M2 (5 hours at 100% brightness + 5 hours PIR with 25% dim light + 70% brightness until dawn, M2) / lighting mode M3 (70% brightness until dawn, M3) |
| Warranty | |
|---|---|
| Battery Cycle Life | 1,500 |
| Warranty | 3 years |
| IP Rating | IP65 |
