Emergency LED Battery Backup Driver-wattage selectable-(8W-12W-15W) BLD-AM15D-480600

Spec Sheet BLD-AM15D-480600
Model Name BLD-AM15D-480600
Input Voltage 100-347Vac, 50/60Hz
Emergency Power 15W
Warranty 5 years


Emergency LED Backup Battery Driver 15Watts Constant Output Power


  • Input Voltage:100-277V      50/60HZ
  • AC Input Current:   100mA   max
  • AC Input Power Rating:15W max
  • Output Current and Voltage:  320-600mA   25V-48V  Class 2
  • Output Power:  8W, 12W, 15W max
  • Illumination Time:   90 Minutes
  • Test Switch Charging Indicator Light:  Low Voltage, luminated Test Switch
  • Battery Charging Current:  250mA
  • Recharge Time:    24Hours
  • Temperature Rating Ambient: 0°C to + 50°C (32°FF to 122°F)
  • Dimensions: 15”x2.17”x1.3”(382mmx55mmx32mm)
  • Weight: 3.2 lbs(1.45kg)
