Canopy WAT & CCT Tunable 75W
Canopy WAT & CCT Tunable 75W
Model: E2-CAN-45/55/75W-30/40/50K
45/55/75W Wattage Selectable, 9,750 Lumens
3000K/4000K/5000K CCT Selectable
0-10V Dimmable
120-277 Volt
IP65
Specifications
| Wattage | 45W / 55W / 75W |
| Voltage | 120-277V |
| Dimming | 0-10V |
| CCT | 3000K / 4000K / 5000K |
| CRI | > 80 |
| Lumens | 9750 lm |
| Dimensions | 10.55 × 9.88 in / 2.83 in / 3.43 in |
| Listings | IP65 Rating, UL Listed |
| Warranty | 5-Year Manufacturer's Warranty |
| Light Source | SMD LED |
| Efficacy | 130 lm/W |
| Power Factor | 0.9+ |
| CCT Selectable | Yes, switchable |
| Wattage Selectable | Yes |
| Family | Canopy and garage light |
| Series | CSA canopy |
Description
A low-profile LED canopy light with wattage and color temperature both set in the field, so one fixture can match the light level and tone of an existing canopy, garage or walkway. Wattage is selectable at 45W, 55W or 75W, for up to 9,750 lumens at 130 lm/W, and color temperature at 3000K, 4000K or 5000K, with CRI 80+.
It dims with 0–10V controls and runs on 120–277V. The IP65-rated housing measures 10.55 × 9.88 inches.
UL listed, with a 5-year warranty.
Specifications
| General | |
|---|---|
| Family | Canopy and garage light |
| Series | CSA canopy |
| Light Source | SMD LED |
| Light | |
|---|---|
| CCT | 3000 / 4000 / 5000K |
| CRI | 80+ |
| Efficacy | 130 lm/W |
| Lumens | 9,750 lm |
| Electrical | |
|---|---|
| Power Factor | 0.9+ |
| Voltage | 120–277V |
| Wattage | 45 / 55 / 75W |
| Physical | |
|---|---|
| Dimensions | 10.55 × 9.88 in / 2.83 in / 3.43 in |
| Controls | |
|---|---|
| CCT Selectable | Yes, switchable |
| Dimming Type | 0–10V |
| Wattage Selectable | Yes |
| Warranty | |
|---|---|
| Warranty | 5 years |
| Certifications | UL |
| IP Rating | IP65 |
