E2 Lighting Inc.


Linear High Bay Light

Spec Sheets E2MLH03-Linear Highbays data sheet
Wattage 90W(2ft) , 130W(2ft), 180W (2ft )
Light Output 11,800 LM, 17,650 LM, 24,500 LM
Efficacy 130 Lm/W
DLC Premium 4.3


The linear high-bay lights are designed to illuminate high ceilings across their entire length. Wider and longer than the regular UFO lights, these lights offer a clear, and uniform lighting throughout the area. Being one of the leading manufacturer and supplier of the energy-efficient LED lighting solutions, E2Lighting offers the widest range of high bay lights to be used in large recreational facilities, gyms and more. E2’s linear high bay light offers high efficiency and light output that makes them an ideal replacement for all types of traditional industrial lamps. Equipped with a linear high bay motion sensor. E2’s high bay lights are constructed using high-quality components that ensure the longevity of the product.

Specifications of Linear LED High Bay Lights

At E2 Lighting, provide the linear high bay lights in the following specifications:

  • Technical Requirements Version: 4.4
  • Classification: Premium
  • Dimming Compatible: Yes
  • Light Output:  12,420, 16,900, 23,400, and 39,000 lm
  • Wattage: 90W, 130W, 180W and 300W
  • Efficacy: 139, 140, 152, 145, 146, 144 lm/W
  • Power Factor: 0.90
  • CCT: 4000, 4500, 5000 K
  • Input Voltage: AC100-277V
  • IP Rating: IP44
  • Working Environment: –4ºF-156ºF
  • Beam Angle: 120º
  • CRI: >84
  • THD: <24 %
  • Frequency: 47-63Hz
  • Mercury Content: No Hg
  • Lens: Polycarbonate
  • Net Weight: 7.05 lbs for 80W, 9.70 lbs for 130W, 12.13 lbs for 180, 14.55 lbs for 300W

Applications of Linear LED High Bay Lights

E2’s linear high bay lights are becoming replacements for several traditional lighting solutions. At E2 Lighting, we have been delivering linear high bay lights for use in:

  • Warehouses and Distribution Centers
  • Retail Stores
  • Indoor Sports Courts
  • Commercial Facilities
  • Aisles
  • Gymnasiums and Field Houses
  • Municipalities and Schools
  • Gas Stations
  • Hangars
  • Exhibition Halls


E2Lighting USA ensures that all the LED lighting solutions will be free from material workmanship and material defects for a period of 5 years from the delivery date. This product warranty offered by us covers factors including coverage of light output, fixture finish, driver performance, color stability and more.

Certifications and Standards

E2Lighting USA is committed to delivering the perfect LED lighting solutions. All these products are designed with a higher degree of professional competence.
At E2Lighting USA, we ensure that all our rebatable lighting solutions including LED linear high bay lights meet the following standards, as well as certifications:

  • UL and ETL Classified/Recognized
  • DLC Premium Listed
  • RoHS Compliant
