Model: E2-WP-M-15W-35/40/50K-E-BK-Cold
15W, 1,870 Lumens
3500K/4000K/5000K CCT Selectable
Integrated Photocell
Built-in 5W Emergency Battery, 90 Minutes
120-277 Volt
IP65
Black Finish
| Wattage | 15W |
| Voltage | 120-277V |
| CCT | 3500K / 4000K / 5000K |
| CRI | 72+ |
| Lumens | 1,870 lm (at 15W) |
| Lifespan | 50,000 hours |
| Dimensions | 10.4" × 6.5" × 3.8" |
| Listings | DLC Standard, IP65 Rating, UL Listed |
| Warranty | 5-Year Manufacturer's Warranty |
| Cold Temperature Rated | -20C to 50 C |
| Light Source | COB LED |
| Efficacy | 120 lm/W |
| Current | 0.14A (at 120V) / 0.05A (at 277V) |
| Ambient Temperature | -4–122 °F / -20–50 °C (operating) |
| Color | Black |
| Recharge Time | 24 hours |
| Conversion Time | up to 0.2 seconds |
| Emergency Backup | Integrated |
| Emergency Lumens | 600 lm |
| Emergency Power | 5W |
| Emergency Runtime | 90 minutes |
| Test Switch | Test button (manual) |
| CCT Selectable | Yes, tunable |
| Daylight Threshold | 3 fc |
| Photocell | Included |
| Flame Retardant | UL-94V-0 flame rating |
| Family | Wall pack and wall luminaire |
| Series | WPM mini wall pack with photocell |
A black mini LED wall pack with an integrated emergency battery and a built-in photocell, for building exteriors that need light during an outage. The emergency battery is rated 5W and provides 90 minutes of backup, with a test button on the fixture.
Color temperature is selectable at 3500K, 4000K or 5000K at 15W, giving 1,870 lumens at 120 lm/W with CRI 72+. It runs on 120–277V and measures 10.4 × 6.5 × 3.8 in. The IP65 rating and -20 to 50 °C operating range suit it to outdoor walls.
UL listed, with a 50,000-hour rated life and a 5-year manufacturer's warranty.
| General | |
|---|---|
| Family | Wall pack and wall luminaire |
| Series | WPM mini wall pack with photocell |
| Light Source | COB LED |
| Light | |
|---|---|
| CCT | 3500K / 4000K / 5000K |
| CRI | 72+ |
| Efficacy | 120 lm/W |
| Lumens | 1,870 lm (at 15W) |
| Electrical | |
|---|---|
| Current | 0.14A (at 120V) / 0.05A (at 277V) |
| Voltage | 120–277V |
| Wattage | 15W |
| Physical | |
|---|---|
| Ambient Temperature | -4–122 °F / -20–50 °C (operating) |
| Dimensions | 10.4 × 6.5 × 3.8 in |
| Finish | Black |
| Emergency | |
|---|---|
| Charge Time | 24 hours |
| Conversion Time | up to 0.2 seconds |
| Emergency Backup | Integrated |
| Emergency Lumens | 600 lm |
| Emergency Power | 5W |
| Emergency Runtime | 90 minutes |
| Test Switch | Test button (manual) |
| Controls | |
|---|---|
| CCT Selectable | Yes, tunable |
| Daylight Threshold | 3 fc |
| Photocell | Included |
| Warranty | |
|---|---|
| Rated Life | 50,000 hours |
| Warranty | 5 years |
| Certifications | UL / DLC Standard |
| Flame Retardant | UL-94V-0 flame rating |
| IP Rating | IP65 |
